Applications in the field of transmissions

A transmission is essential for all cars with a combustion engine. Whether manual transmission, automatic transmission or dual clutch transmission – all contain countless precision parts which can be perfectly machined on machines from Schaudt Mikrosa GmbH.

The gear converter is connected directly downstream of the engine and converts speeds and torques along the power train. The aim is to make the engine as efficient as possible, with the highest possible driving dynamics. Whether manual transmission, automatic transmission or dual clutch transmission – all contain countless precision parts which can be perfectly machined on machines from Schaudt Mikrosa GmbH.

As a partner to the automotive industry and its suppliers, SCHAUDT MIKROSA offers efficient machining solutions for many applications in the field of transmissions. The SCHAUDT ShaftGrind series, which is based on the proven camshaft grinding platform CamGrind, is perfectly designed for grinding input, output or intermediate shafts. For centerless grinding applications, all machine sizes in MIKROSA’s KRONOS series are used. They can machine precision workpieces such as control spools for control units, planetary gear pins, shifter rods or needles for needle bearings with great efficiency.

Centerless cylindrical grinding machine KRONOS S 250

Centerless cylindrical grinding machine KRONOS S 250

Grinding of gear shafts

The conventional machining process for a gear shaft is difficult to standardize. Flexible solutions and new approaches are needed here. Different qualities of the bearing positions along a workpiece, divergent references for bearing positions and centers as well as the machining of bearing, keyway and spline diameters and shoulder surfaces place high demands on both machine and grinding process.

SCHAUDT meets these challenges with the ShaftGrind series, which offers an individual combination of suitable machining and machine concepts for every grinding task. From concepts with one grinding wheel to fully flexible solutions with up to four grinding wheels, any machine configuration is possible. The result are highly efficient and relatively cost-effective solutions for transmission manufacturers.

Multiple production for high productivity.

Multiple production for high productivity.

The ShaftGrind S can be equipped with 2 grinding spindles, for example. The shaft diameters are ground with a ceramic-bound CBN grinding wheel on the main spindle, while the swivel-in spindle for machining the shoulders has a galvanic-bound CBN grinding wheel set. Thanks to integrated first contact detection the cycle time can be significantly reduced, as the machine detects fluctuations in the rough part stock allowance and only switches from rapid feed to grinding feed in the case of contact.

Gear shafts can be machined even more effectively on the ShaftGrind L2. This machine is equipped with two cross slide systems with up to four grinding spindles (two main spindles and two swivel-in spindles), which can operate simultaneously. This allows the grinding time for diameter machining to be almost halved. In-process measuring heads monitor the diameter dimensions to ensure production reliability. Swivel-in spindles with galvanic-bound CBN grinding wheel sets are used for machining the keyways. The machine thus achieves an unbeatable productive cycle time, together with high process reliability.

ShaftGrind with Multiwheel Transmission Shaft Technology.

ShaftGrind with Multiwheel Transmission Shaft Technology.

Multiwheel Transmission Shaft Technology

The Multiwheel Transmission Shaft Technology has been developed specifically for highly productive gear shaft applications. It allows synchronous machining of all bearing positions and spline diameters in a single plunge. A grinding tool with several wheels has been developed, which isolates spline machining from diameter machining in terms of vibrations. Combined with our technology and experience, machining times of just 15 seconds can be achieved. If plane surfaces and flat shoulders are also machined, the machines’ wheelhead can be extended by a swivel-in spindle in accordance with the performance criteria. The concept is thus perfectly designed for maximizing productivity in gear shaft machining.

However, centerless machining can also be used for gear shafts. On machines of the KRONOS series all seats are ground in a single plunge, including machining of the spline gear. In this case too, it is difficult to prevent the transmission of rounding errors from the gear to the diameters. A great deal of experience is needed for the configuration and set-up of the grinding process, and we have this at MIKROSA. A fundamental advantage of centerless grinding is that the workpiece is supported along its lateral surface on the workpiece rest and on the regulating wheel, so that any deflection of the shaft can be prevented. This enables excellent quality as well as a short grinding time.

Highly productive grinding of gearshafts in one single plunge.

Highly productive grinding of gearshafts in one single plunge.

Centerless machining for precision parts

In addition to the various gear shafts there are many other precision workpieces in the transmission which are ideal for centerless machining. Planetary gear pins, which are found in large quantities and different sizes in every automatic transmission, and needles for needle bearings are ideally suited for through grinding, for example. However, these parts must not only be produced precisely, but also quickly and cost-effectively. Needles with an allowance of 0.1 mm, a workpiece diameter of 5 and a length of 16 mm, are ground on a KRONOS M 400, for instance, at a speed of up to 16 meters per minute. This gives roughly 1000 finished parts per minute. The machines are real endurance runners. Dressing occurs continuously and in parallel with the grinding process. So while machining is underway on the front side of the grinding wheel, the rear side is dressed simultaneously. However, in addition to high productivity, these workpieces also have extreme demands on surface quality. Impressive values of Rz 0.4 and 0.5 microns are achieved when machining planetary gear pins – and that’s with grinding!

Throughfeed grinding of planetary gear pins on a KRONOS L

Throughfeed grinding of planetary gear pins on a KRONOS L

Other workpieces are ground using the plunging method in single or multiple production. Control spools, found in great variety in the control units of automatic and dual clutch transmissions, can be machined highly efficiently on a KRONOS S 250 in fourfold production, for example. Shifter rods for manual transmissions are ground on a KRONOS L 660 in double production. This allows for a significant reduction of cycle times and a considerable decrease of unit costs, despite higher investment costs. The machines are part of a complete machining line. The parts are fed into the machine via a handling system, machined and finally measured and palletized.
